HDMI® CAT5e Extender-Single CAT5e cable 1080p

SKU: HE01ERK

In Stock

Regular price
$61.20
$61.20
Regular price
Sale price
$68.00
Unit price
 per
Volume order: Request a quote
  • Resolution up to 1080p.
  • Singal extension up to 70M.
  • No external power required.
  • Built-in micro USB connector to stabilize the signal in a long cable run.

Description

Package

Specification

Downloads

HE01ERK is an HDMI® extender that supports the transmission distance up to 70 meters and resolution up to 1080p@60Hz. You can simply use an economical CAT5e cable to extend the signal without any power adapter. The extender is also built with the dongle design, allowing you to directly connect to an HDMI display without actually applying an HDMI® cable.

Passive Type, Plug-and-Play, Handy HDMI® Extender

Use a Small Plug to Send an HDMI® Signal over CAT5e

HE01ERK is an HDMI® Extender, with Built-in Chipset, and Easy Installation

With the transmitter (on the HDMI source side) and the receiver (on the display side), HE01ERK can use a single CAT5e network cable to display an HDMI® signal on a remote monitor.

HE01ERK is widely used in the scenario that requires short distance extension for HDMI® signals, such as NVR to monitor, PC to TV...etc. It's a compact device that can easily and quickly install your A/V environment.

Easy Installation, Plug-and-Play

HE01ERK is easy to operate. Only need to use one network cable to connect the transmitter and the receiver. No configuration required.

Special Designed, Mini Micro USB on transmitter Unit

Although the price of some passive-type HDMI extenders is cheap, there are a variety of complaints about the extender sold on eCommerce websites. The most common issue is that the products can not function as advertised, which includes:

  • Short transmission distance, even using high-quality cables.
  • Video/ audio loss.
  • Image distortion.
  • Wrong instruction to cause improper installation.

Mini USB Design

The extender typically extends the signal based on the 5V power from the HDMI source device, high-quality cables, and installation environment. To remain a stable connection, the mini USB port allows you to solve the following issues:

  • When the environment has interference, you can use the mini USB port to provide sufficient power to stabilize the connection.
  • The mini USB port can also act as an indicator that helps installers to identify transmitters from receivers.

Application

Why Choose SC&T?

Mature Product

From 2017 to the present, the product has been sold in over 20,000 pairs used in Pro AV and CCTV markets.

Perfect Cooperation

We don't sell our products on any eCommerce platform to compete with our partners, ensuring they have great margins selling our products.

Experienced Support Team

SC&T has a strong FAE team with 20 years of experience to help you solve technical issues.

Installation

Follow the instructions below to install the product.

  • Make sure Tx connects to the source device and Rx connects to the display.
  • Keep a distance between link cables and equipment with electromagnetic waves, such as microwaves, cellphones, power cables, and more.
  • Do NOT bend the link cables, avoiding signal interference and unstable connection.
  • The transmission distance may vary by connected devices.
  • Do NOT use STP cables. Otherwise, the video can not be shown properly.
  • It's highly recommended to use high-quality CAT5e/ CAT6 cables.
  • The product does NOT support HDCP protocol.
  • The product does NOT use the AVoIP technology.

  • HE01SET (Transmitter) x 1
  • HE01SER (Receiver) x 1
  • Micro USB to DC plug cable x 1
ITEM NO. HE01SET HE01SER

Support

Compliance HDMI 1.3, 3D
Max. Video Resolution 1080p@60Hz
Max. Transmission Distance 70M at 720p, 40M at 1080p
Video Bandwidth 2.25 Gbps
Audio Format LPCM 2.0

Ports & Interfaces

Video Input 1 x HDMI® Type-A 1 x RJ45
Video Output 1 x RJ45 1 x HDMI® Type-A
Power Interface 1 x Micro USB

Power

Power Supply DC 5V 1A (Optional)
Power Consumption 600mA

Ambient Temperature

Operation 0 to 55℃
Storage -20 to 85℃
Humidity Up to 95%

Physical Characteristic

Dimensions 57.5 × 24 × 20.2mm 57.5 × 24 × 20.2mm
Weight 20g 20g
